Built units
Units available now
Two units are complete and ready for occupation immediately.
Unit SPC 220
SPC 220 features a 209,081 sq ft warehouse with 11,206 sq of office accommodation.
Read more about Unit 4B
Unit SPC 140
SPC 140 features a 131,761 sq ft warehouse with 8,580 sq of office accommodation.
Read more about Unit 4CSPC 220 - 220,512 Sq Ft Warehouse / Industrial Unit - Available Now
Summary
Warehouse
- 209,081 sq ft
- 15m to haunch
- 20 dock levellers (including 4 Eurodocks)
- 2 level access doors
- Internal Floor slabs laid to FM2 specification - 50kn/m2 floor loading
- Concrete service yards 50m deep
- 204 car parking spaces; with 20% electric vehicle charging points
- 25 year warranty for the cladding system
- 700 kVA electric supply
- Example pallet capacity
- Very Narrow Aisle c. 38,000
- Wide Aisle c. c. 30,000
Office
- 11,206 sq ft (with undercroft)
- Raised floors
- Suspended ceilings
- Comfort cooling
- LED lighting with PIR and perimeter daylight sensitive controls daylight sensitive controls
- Kitchen and shower facilities
Sustainability
- EPC A rating
- BREEAM Excellent
- 711 sq m PV panels
- 13 dual head, 7.4kW EV chargers
- 12% rooflights
- Air leakage 2.5m3/hr/m²
- Solar thermal water heating system
- Rain Water Harvesting
Warehouse and Floor Plans
Accommodation
All areas are approximate and measured on a Gross internal basis.
| Warehouse | 209,081 sq ft |
| 19,424 sq m | |
| Offices | 11,206 sq ft |
| 1,041 sq m | |
| Gate house | 225 sq ft |
| 21 sq m | |
| Plot area | 10 acres |
| 4 Ha | |
| Total | 220,512 sq ft |
| 20,486 sq m |
Unit SPC 140 - 140,567 Sq Ft Warehouse / Industrial Unit - Available Q4 2023
Summary
Warehouse
- 131,761 sq ft
- 15m to haunch
- 12 dock levellers (including 2 Euro docks) and 2 level access doors
- Internal Floor slabs laid to FM2 specification - 50kn/m² floor loading
- Concrete service yards 50m deep
- 130 car parking spaces; 20% with electric vehicle charging points
- 25 year warranty for the cladding system
- 500 Kva Electric Supply
- Example pallet capacity
- Very Narrow Aisle c. 20,000
- Wide Aisle c. c. 16,000
Office
- 8,580 sq ft (with undercroft)
- Raised floors
- Suspended ceilings
- Comfort cooling
- LED lighting with PIR and perimeter daylight sensitive controls daylight sensitive controls.
- Kitchen and shower facilities
Sustainability
- EPC A rating
- BREEAM Excellent
- 711 sq m PV panels
- 13 dual head, 7.4kW EV chargers
- 12% rooflights
- Air leakage 2.5m3/hr/m²
- Solar thermal water heating system
- Rain Water Harvesting
Warehouse and Floor Plans
Accommodation
All areas are approximate and measured on a Gross Internal basis.
| Warehouse | 131,761 sq ft |
| 12,241 sq m | |
| Offices | 8,580 sq ft |
| 797 sq m | |
| Gate house | 226 sq ft |
| 21 sq m | |
| Plot area | 6 acres |
| 3 Ha | |
| Total | 140,567 sq ft |
| 13,059 sq m |
Key Scheme Specification
Built Space
215 acre development site for up to 3.7 million sq ft on a private estate with 24-hr security / management which is accessed via new road junction off the A45.
Sustainability
SEGRO Park Coventry is targeting BREEAM ‘Excellent’, EPC ‘A’ for all units and will feature translucent panels to warehouse walls and roof providing natural daylight, electric car charging points, photovoltaic panels and LED lighting.
